Combination antennas (or combo antennas) integrate multiple individual antennas into a single unit. Each combo antenna supports different technologies and frequency bands, enabling IoT devices to maintain multiple forms of connectivity. In some applications, this ensures always-on connectivity, while in others, the priority may be minimizing cost or maximizing bandwidth.

Combination antennas now offer extensive design possibilities. Designs are only limited by the space available, and we can swap and change internal antenna elements to support any frequency band required to meet bespoke specifications. Although relatively complex to develop, installation is also straightforward because designers only require one mounting point for the entire assembly. And, while cost and complexity have previously limited the potential of this market, this is now rapidly changing.

In recent years, the cost and complexity of producing combo antennas have dropped significantly and they are now accessible to a broader range of users. Manufacturers like Quectel can then reduce development and production expenses by reusing proven form factors at scale. We also lower costs by integrating antenna technologies originally developed for other IoT devices into our combo designs and pass these savings on to customers. We further leverage our in-house manufacturing capabilities and strong supplier relationships to reduce the price of housings and other components.

To meet diverse application needs, we offer a broad range of combo antennas tailored to individual customer requirements. Our models include all possible antenna types, fully tested and isolated, that fit into unified form factors without interference. This enables use cases which would not previously have been viable.

We can also deliver them as part of a complete solution that includes both the antenna and the module. Additionally, we provide semi-custom options and modifications, such as adjustable cable lengths and different connector types, ensuring our combo antennas meet your specific needs. Explore our range of combination antennas below.

Our combo antennas

Image	Frequency	Mounting	Dimensions	See more
	Wi-Fi: 2400-2500MHz, 5150-7150MHz	Adhesive	78.6mm × 21.4mm
	LTE/5G: 600-6000MHz	Adhesive	237mm × 22mm
	5G: 600–960MHz, 1420–2690MHz, 3300–6000MHz Wi-Fi: 2400–2500MHz, 5150–5850MHz, 5925–7125MHz	Adhesive	125mm × 36.4mm
	5G: 600–960MHz and 1400–6000MHz GNSS: 1559–1610MHz	Adhesive	120.85mm × 20.4mm

Image	Frequency	Mounting	Dimensions	See more
	LMHs: 600-960MHz, 1400-6000MHz MHs: 1400-6000MHz GNSS: 1164-1189MHz, 1559-1606MHz	Screw	Φ 167mm × 57mm
	LTE: 700–960MHz, 1710–2690MHz GNSS: 1565–1606MHz	Screw	Ø 81.4mm × 16.5mm
	5G: 600MHz–960MHz, and 1400MHz–6000MHz Wi-Fi: 2400MHz–2500MHz	Screw	Φ 40.6mm × 104mm
	LMHs: 600–960MHz, 1400–6000MHz MHs: 1400–6000MHz GNSS: 1166–1186MHz, 1559–1606MHz	Screw	204mm × 86.6mm × 31mm
	LMHs: 600–960MHz, 1400–6000MHz MHs: 1400–6000MHz GNSS: 1164–1189MHz, 1559–1606MHz	Screw	Φ103.5mm × 42.5mm
	LMHs: 600–960MHz, 1400-6000MHz GNSS: 1164–1189MHz, 1559–1606MHz	Screw	Φ162mm × 56mm
	LTE: 700-960MHz, 1700-2700MHz Wi-Fi/BT: 2400-2500MHz, 5150-5850MHz GNSS: 1559-1606MHz	Adhesive	143.73mm × 51.33mm × 15mm
	LMHs: 600–960MHz, 1400–6000MHz MHs: 1400–6000MHz GNSS: 1164–1189MHz, 1559–1606MHz	Adhesive	264.6mm × 157.6mm × 30.5mm
	4G: 700–960MHz, 1710–2690MHz Wi-Fi: 2400–2500MHz, 5150–5850MHz, 5925–7125MHz GNSS: 1565–1606MHz	Magnetic/Adhesive/Screw	109.28mm × 89mm × 25.8mm
	4G: 700–960MHz, 1710–2690MHz GNSS: 1565–1606MHz	Magnetic/Adhesive/Screw	109.28mm × 89mm × 25.8mm
	4G: 700–960MHz, 1710–2690MHz GNSS: 1559–1606MHz	Magnetic/Adhesive/Screw	109.28mm × 89mm × 25.8mm
	4G: 700–960MHz, 1710–2690MHz Wi-Fi: 2400–2500MHz, 5150–5850MHz, 5925–7125MHz GNSS: 1565–1606MHz	Magnetic/Adhesive/Screw	109.28mm × 89mm × 25.8mm
	5G: 410-470MHz, 617–960MHz, 1420-1520MHz, 1710-2690MHz, 3300–3800MHz, 4000-6000MHz	Pole/Wall/Suction	186mm × 176mm × 100.5mm
	5G: 410-470MHz, 617-2690MHz, 3300-6000MHz	Pole/Wall/Suction	186mm × 176mm × 150mm
	Wi-Fi 1: 2400–2500MHz; 5150–5850MHz Wi-Fi 2: 2400–2500MHz; 5150–5850MHz	Screw	Φ 46mm × 16mm
	4G × 2: 698–960MHz, 1710–2690MHz GNSS: 1565–1606MHz	Screw	Φ 81mm × 15.5mm
	4G: 700–960MHz, 1700–2690MHz GNSS: 1565–1606MHz	Screw	89.3mm × 86.3mm × 35.4mm
	LMHs: 600–6000MHz MHs: 1400–6000MHz	Screw	Φ 103.5mm × 42.5mm
	LMHs: 600–6000MHz GNSS: 1164–1189MHz, 1559–1606MHz	Screw	Φ 103.5mm × 42.5mm
	4 × 5G/4G LMH: 600–960MHz, 1400–6000MHz 2 × 5G/4G MH: 1400–6000MHz 1 × Active GNSS: 1565–1606MHz	Adhesive	133mm × 73mm × 19.1mm
	LMHs: 600–960MHz, 1400–6000MHz MHs: 1400–6000MHz GNSS: 1164–1189MHz, 1559–1606MHz	Screw	Φ 162mm × 56mm
	1710–2690MHz	Pole	774mm × 400mm × 400mm
	698–960MHz	Pole	850mm × 645mm × 850mm
	617–4200MHz	Pole/Wall	590mm × 419mm × 143mm
	1–7000MHz	Screw	225mm × 145mm × 56.4mm
	4G x 2: 698–960MHz, 1710–2690MHz	Adhesive	143.73mm × 51.33mm × 15mm
	4G: 698–960MHz, 1710–2690MHz GNSS: 1559–1606MHz	Adhesive	Φ 82mm × 18.2mm
	5G: 600–960MHz, 1400–6000MHz Wi-Fi: 2400–2500MHz	Screw and adhesive	Φ 40mm × 72mm
	4G x 2: 698–960MHz, 1710–2690MHz GNSS: 1559–1606MHz	Adhesive	Φ 82mm × 18.2mm
	5G: 600–960MHz, 1700–2690MHz, 3300–6000MHz GNSS: 1559–1606MHz	Screw	Φ 50mm × 48mm
	4G: 698–960MHz, 1710–2690MHz GNSS: 1565–1606MHz	Screw	Φ 46mm × 16mm
	698–960MHz, 1710–2690MHz	Screw	Φ 46mm × 15mm
	5G: 698–960MHz, 1420–2690MHz, 3300–6000MHz Wi-Fi: 2400–2500MHz, 5150–5850MHz, 5925–7125MHz	Screw and adhesive	Φ 81mm × 15.5mm
	4G x 2: 698–960MHz, 1710–2690MHz	Screw	Φ 81mm × 15.5mm
	5G: 600–960MHz, 1700–2690MHz, 3300–6000MHz Wi-Fi: 2400–2500MHz, 5150–5850MHz, 5925–7125MHz GNSS: 1559–1606MHz	Screw	Φ 50mm × 48mm
	5G: 698–960MHz, 1420–2690MHz, 3300–6000MHz Wi-Fi: 2400–2500MHz, 5150–5850MHz，5925–7125MHz GNSS: 1565–1606MHz	Screw and adhesive	Φ 81mm × 15.5mm
	4G: 698–960MHz, 1710–2690MHz 4G-DIV: 698–960MHz, 1710–2690MHz GNSS: 1559–1606MHz	Screw	Φ 81mm × 15.5mm
	5G: 600–960MHz, 1710–2690MHz, 3300–6000MHz	Magnet, adhesive, and screw	Φ 54mm × 91.8mm
	5G: 617–960MHz, 1420–2690MHz, 3300–6000MHz Wi-Fi: 2400–2500MHz, 5150–5850MHz, 5925–7125MHz GNSS: 1565–1606MHz	Screw and adhesive	Φ 54mm × 91.8mm
	4G: 698–960MHz, 1710–2690MHz Wi-Fi: 2400–2500MHz, 5150–5850MHz GNSS: 1559–1606MHz	Screw	89.3mm × 86.3mm × 35.4mm
	4G × 2: 698–960MHz, 1710–2690MHz GNSS: 1559–1606MHz	Adhesive	Φ 82mm × 18.2mm
	LMHs: 600–960MHz, 1400–6000MHz MHs: 1400–6000MHz GNSS: 1164–1189MHz, 1559–1606MHz	Screw	Φ 167mm × 57mm
	LMH: 600–6000MHz MH: 1400–6000MHz GNSS: 1164–1189MHz, 1559–1606MHz	Screw	Φ 103.5mm × 42.5mm
	5G: 600–960MHz, 1700–2690MHz, 3300–6000 MHz Wi-Fi: 2400–2500MHz, 5150–5850MHz, 5925–7125MHz GNSS: 1559–1606MHz	Screw	Φ 50mm × 48mm
	LMH: 600–960MHz, 1400–6000MHz	Screw M20	Φ 103.5mm × 42.5mm
	LMH: 600–960MHz, 1400–6000MHz GNSS: 1164–1189MHz, 1559–1606MHz	Screw	204.4mm × 86.7mm × 32mm
	LMH: 600–960MHz, 1400–6000MHz	Screw	204.4mm × 86.7mm × 32mm
