YEMN016AA 5G/GNSS screw mount 5-in-1 combo antenna box

  • Frequency range – LMHs: 600–960MHz, 1400–6000MHz
  • Frequency range – MHs: 1400–6000MHz
  • Frequency range – GNSS: 1166–1186MHz, 1559–1606MHz
  • Dimensions: 204.4mm x 86.7mm x 32mm
  • Cable lengths (various): 300-5000mm
  • IP rating: IP67 & IP69K
  • RoHS and REACH compliant
Please enable JavaScript in your browser to complete this form.
Checkboxes

Have a question? Contact us

Key features

  • Optimized for 5G/4G networks
  • 4 x 4 5G/4G MIMO
  • GPSS L1 & L5
  • Screw mount
  • SMA (male) connector
  • Durable KIBILAC® ASA housing

Overview

This ultra-wide-band 5G/4G antenna box provides broad coverage from 600-6000MHz whilst backward-compatible to support 3G/2G networks as well at Cat-M and NB-IoT. The combo antenna is designed to work with various GND plane sizes or in free space for ease of integration with connection, with connection via 5 cables of customizable length between 300-5000mm, terminated with SMA connectors.

This screw mount omnidirectional IoT antenna is easy to install with maximum durability with its IP67 & IP69 KIBILAC® ASA enclosure. It is compatible with Quectel’s RM520x Series modules. Quectel provides comprehensive antenna design support such as simulation, testing and manufacturing for custom antenna solutions to meet your specific application needs.

Simplify deployment by sourcing antennas at the same time as your modules – see our wide range here

Product Brochure

Quectel-Product-Brochure-V7.7.pdf

Download
