Wi-Fi modules connect IoT devices to Wi-Fi networks, a form of short-range connectivity. Wi-Fi’s sixth generation Wi-Fi 6 represents a dramatic improvement over its predecessors, with maximum output of 9.6Gbps over Wi-Fi 5’s 3.5Gbps, much reduced latency, and superior ability to support multiple devices.

Quectel’s Wi-Fi 6 modules are designed to deliver faster, more secure and more robust Wi-Fi experiences than ever before, as well as new Bluetooth audio capabilities. When used in combination with our 5G modules, these offer superior 5G and Wi-Fi 6 performance for MiFi and CPE designed to ensure high-speed connections supporting up to 32 clients at a time, guaranteeing ultrareliable connections for multi-user scenarios such as smart homes, shopping malls, schools and factories.  And as more and more consumer industries are now investing in the intersection of cutting edge Wi-Fi and 5G connectivity, Wi-Fi 6 enterprise access point shipments will increase from 4.3m in 2021 to 13.4m in 2026, at a CAGR of 25%. The time for solution builders to plan too for that market expansion is surely now.

  • Automotive
  • Customer-premise equipment
  • Digital healthcare
  • Digital signage
  • Home gateways
  • IP camera
  • MiFi
  • Mobile computing
  • Mobile POS
  • Projectors
  • Remote monitoring and control
  • Set-top boxes
  • Smart homes
  • Smart metering
  • Telematics
  • Video applications
  • Module Protocol Bluetooth Interfaces See more
    Wi-Fi 7 BT 5.4
    PCM//SLIMBus (BT audio) × 1
    PCIe 3.0 (Wi-Fi) x 1
    UART (BT) × 1
    Antenna (Wi-Fi/BT) × 2
    Wi-Fi 7 BT 5.4
    PCM/I2S (BT audio) × 1
    PCIe 3.0 (Wi-Fi) x 1
    USB (BT) × 1
    Antenna (Wi-Fi/BT) × 2
    Wi-Fi 7 BT 5.4
    PCM/I2S (BT audio) × 1
    PCIe 3.0 (Wi-Fi) x 1
    USB (BT) × 1
    Antenna (Wi-Fi/BT) × 2
    Wi-Fi 7 BT 5.4
    PCM//SLIMBus (BT audio) × 1
    PCIe 3.0 (Wi-Fi) x 1
    UART (BT) × 1
    Antenna (Wi-Fi/BT) × 2
    Wi-Fi 7 BT 5.4
    PCM/I2S (BT audio) × 1
    PCIe 3.0 (Wi-Fi) x 1
    USB (BT) × 1
    Antenna (Wi-Fi/BT) × 2
    Wi-Fi 7 BT 5.3
    PCM (Wi-Fi) × 1
    PCIe (BT) x 1
    UART (BT) × 1
    Antenna (Wi-Fi/BT) × 2
    Wi-Fi 7 BT 5.3
    PCM (Wi-Fi) × 1
    PCIe (BT) x 1
    UART (BT) × 1
    Antenna (Wi-Fi/BT) × 2
    Wi-Fi HaLow N/A
    PCM × 1
    SPI × 1
    Wi-Fi antenna × 1
    Wi-Fi 6 BT 5.3
    PCM × 1 (for Bluetooth)
    PCIe 3.0 × 1 (for Wi-Fi)
    UART × 1 (for Bluetooth)
    Wi-Fi/BT antenna interface × 1
    Wi-Fi 6 BT 5.2
    GPIO
    PWM
    I2C
    UART
    ADC
    PCB antenna interface
    Wi-Fi 6 BT 5.2
    PCM (BT) × 1
    PCIe (Wi-Fi) x 1
    UART (BT) × 1
    Antenna (Wi-Fi/BT) × 3
    Special pins WLAN_EN, BT_EN
    Wi-Fi 6 BT 5.2
    SDIO 3.0 (Wi-Fi) × 1
    UART (BT) × 1
    Wi-Fi/BT antenna × 1
    Wi-Fi 6 BT 5.2
    SPI (802.15.4) × 1
    SDIO 3.0 (Wi-Fi) × 1
    UART (BT) × 1
    Wi-Fi/BT antenna × 1
    Wi-Fi 6 BT 5.1
    I2C
    SPI
    UART
    I2S
    PWM
    ADC
    RF coaxial connector, external antenna pin, PCB antenna (optional)

    Wi-Fi 5 BT 5.2
    I2C
    SPI
    UART
    GPIO
    PWM
    ADC
    RF coaxial connector, external antenna pin, PCB antenna (optional)

    Wi-Fi 6E BT 5.2
    PCle × 1
    PCM × 1
    UART × 1
    WLAN_EN supported
    BT_EN supported
    Wi-Fi/BT antenna interface ANT_WIFI0, ANT_WIFI1, ANT_BT (optional)

    Wi-Fi 6E BT 5.2
    PCle × 1
    PCM × 1
    UART × 1
    WLAN_EN supported
    BT_EN supported
    Wi-Fi/BT antenna interface ANT_WIFI0, ANT_WIFI1, ANT_BT (optional)

    Wi-Fi 6 BT 5.2
    PCle × 1
    PCM × 1
    UART × 1
    WLAN_EN supported
    BT_EN supported
    Wi-Fi/BT antenna interface ANT_WIFI0, ANT_WIFI1, ANT_BT (optional)
    Wi-Fi 6 BT 5.2
    PCle × 1
    PCM × 1
    UART × 1
    WLAN_EN supported
    BT_EN supported
    Wi-Fi/BT antenna interface ANT_WIFI0, ANT_WIFI1, ANT_BT (optional)
    Wi-Fi 5 BT 5.0
    PCM × 1
    SDIO × 1
    UART × 1
    Special Pin SDIO_VSEL/WLAN_EN/BT_EN
    Wi-Fi antenna × 2
    Bluetooth antenna × 1 (optional)
    Wi-Fi 5 BT 5.0
    SDIO 3.0 × 1
    BT_UART × 1
    PCM × 1
    Wi-Fi/BT antenna × 1
    Wi-Fi 5 BT 5.0
    SDIO 3.0 × 1
    BT_UART × 1
    PCM × 1
    Wi-Fi/BT antenna × 1
    Wi-Fi 4 BT 5.2
    USB 2.0 × 1 (for Bluetooth)
    Special Pin CHIP_ENG
    Wi-Fi/BT antenna interface × 1
    Wi-Fi 4 BT 5.2
    UART × 2
    I2C × 1
    PWM × 1
    GPIO × 4
    Antenna interfaces × 1 (pin, IPEX and PCB are optional)
    Wi-Fi 4 BT 5.2
    PCM × 1 (for Bluetooth)
    SDIO 2.0 × 1 (for Wi-Fi)
    UART × 1 (for Bluetooth)
    Wi-Fi/BT antenna interface × 1
    N/A BT 5.4 I2C/ UART/ SPI/ I2S
    N/A BLE 5.4 18 GPIOs (multiplexed for various interfaces including I2C, UART, SPI, I2S functions)
    N/A BLE 5.4 18 GPIOs (multiplexed for various interfaces including ADC, USART, I2C, I2S, PDM, SPI and PWM)
    N/A BLE 5.4 Up to 18 GPIOs (multiplexed for various interfaces inluding ADC, USART, I2C, PDM, SPI, PWM.)
    N/A BT 5.3 UART/ SWD/ SPI/ I2C/ ADC/ PWM/ I2S antenna interface (optional) × 1 (RF coaxial connector, external antenna pin, PCB antenna)
