Smart IoT modules bring together previously separate functionalities – for instance computing, graphics processing, data storage and connectivity – into single, highly compact pieces of hardware.

The ability to perform such various tasks in a single module removes the need to specify and develop multiple function-specific modules, and then ensure they can be integrated into a unified product; smart modules are therefore a key way for solution builders to simplify designs, reduce size, remove technical limitations, limit costs and accelerate time-to-market. They are in short the cutting edge of integrated hardware in the world of IoT technologies.

Smart modules can support a rich set of peripheral components – such as cameras, LCMs, Wi-Fi, Bluetooth, GNSS, memory and SD cards, eSIM and embedded universal integrated circuit cards (eUICC). They offer a wide choice of interfaces such as USB2.0/3.0, USB type-C, I2C, UART, GPIOs, and support PWM and ADCs. Smart modules also have integrated operating systems – often with a choice of Linux for applications in industrial IoT, or Android for commercial solutions – as well as device drivers and associated SDKs.  Quectel offers a comprehensive range of smart modules, with extensive product families of variants to support deployment regions and a range of interfaces and connection options – to find out more you can browse our webshop from the links below.

  • AR/VR
  • Delivery lockers
  • Digital signage
  • Edge computing
  • In-car entertainment systems
  • PDAs and tablets
  • Robotics and smart factories
  • Smartphones
  • Smart POS
  • Smart home gateways
  • Vending machines
  • Video streaming
  • Wearables
  • Module OS Memory CPU Camera See more
    Android 7.1/8.1
    Yocto Linux
    1GB + 8GB
    or
    2GB + 16GB
    4x A7 @1.1GHz
    2*MIPI_CSI
    Supports 8MP+2MP
    Android 10
    1GB + 8GB
    or
    2GB + 16GB
    4x A53 @1.3GHz
    2*MIPI_CSI
    Supports 8MP+8MP or 13MP
    Android 10
    1GB + 8GB
    or
    2GB + 16GB
    4x A53 @1.4GHz
    2*MIPI_CSI
    Supports 8MP+2MP
    Android 12
    2GB + 32GB
    or
    3GB + 32GB
    4x A53 @2GHz
    2*MIPI_CSI
    Supports 13MP+13MP or 16MP+8MP+2MP
    Android 9/10
    3GB + 32GB
    or
    4GB + 64GB
    4x Kryo @2.2GHz+
    4x Kryo @1.8GHz
    3*MIPI_CSI
    Supports 16MP+16MP or 24MP
    Android 9/10
    2GB + 16GB
    or
    3GB + 32GB
    8x A53 @1.8GHz
    3*MIPI_CSI
    Supports 13MP+13MP or 21MP
    Android 9/10
    2GB + 16GB
    or
    3GB + 32GB
    8x A53 @2.0GHz
    3*MIPI_CSI
    Supports 13MP+13MP or 24MP
    Yocto Linux (Kernel 3.18)
    2GB + 16GB
    8x A53 @2.0GHz
    3*MIPI_CSI
    Supports 13MP+13MP or 24MP
    Yocto Linux (Kernel 5.4)
    2GB + 32GB
    2x QCM2290 @2.0GHz
    4*MIPI_CSI
    Supports 13MP+13MP or 25MP
    Android 10
    4GB + 64GB
    4x Kryo @2.7GHz +
    4x Kryo @1.7GHz
    4*MIPI_CSI
    Supports 16MP+16MP+2MP or 32MP
    Linux
    4GB + 2GB
    2x A53 @1.3GHz Supports VGA display and 5 MP camera
    Android 12
    4GB + 64GB
    or
    6GB + 128GB
    or
    8GB + 128GB
    or
    8gb + 256GB
    1× QCM6490 @2.7GHz +
    3× QCM6490 @2.4GHz +
    4× QCM6490 @1.9GHz
    4*MIPI_CSI
    Supports 27MP + 27MP + 27MP
    or
    22MP + 22 MP + 22MP
    or
    36MP + 27MP
    or
    36MP + 22MP
    or
    36MP
    Android 10
    8GB + 64GB
    1× Kryo @2.842GHz +
    3× Kryo @2.419GHz +
    4× Kryo @1.805GHz
    6*MIPI_CSI
    Supports 25MP+25MP or 64MP ZSL
    Android
    12GB + 256GB 8x Kryo
    4*MIPI_CSI
    Android 10/11/13
    3GB + 32GB
    or
    4GB + 64GB
    4x Kryo @2.0GHz +
    4x Kryo @1.8GHz
    4*MIPI_CSI
    Supports 16MP + 16MP or 24MP
    Linux
    4GB + 64GB
    8x QCx4290
    4*MIPI_DSI
    Supports up to 25MP
    Android 12/13/14
    4GB + 64GB
    8x Kryo
    4*MIPI_CSI
    Supports up to 25MP
    Yocto Linux (Kernel 4.14)
    3GB + 32GB
    or
    4GB + 64GB
    4x Kryo @2.0GHz +
    4x Kryo @1.8GHz
    4*MIPI_CSI
    Supports 16MP + 16MP or 24MP
    Android 13/14/15/16
    4GB + 64GB
    2× A78 @ 2.4GHz +
    6× A55 @ 2GHz
    3*MIPI_CSI, 2*ISP
    Supports up to 64MP NZSL
    Linux (Kernel 4.19/ 5.10)/ Android 13/ OpenWrt
    2GB + 16GB
    or
    2GB + 32GB
    or
    4GB + 32GB
    4× A55 @ 2.0GHz
    4*MIPI_CSI
    Supports up to 2.5 Gbps/lane
    Android 12/13
    2GB + 16GB
    or
    3GB + 32GB
    4× A53 @ 2.0GHz
    4*MIPI_CSI
    Supports 13MP + 13MP or 25MP
