YFMP200WWA Wi-Fi/GNSS L1 2-in-1 SMT mount combo embedded antenna

  • Frequency band – Wi-Fi: 2400–2500MHz
  • Frequency band – GNSS: 1560–1580MHz
  • Dimensions: 3.2mm x 1.6mm x 0.6mm
  • Efficiency: up to 73.1%
  • RoHS and REACH compliant
Please enable JavaScript in your browser to complete this form.
Checkboxes

Have a question? Contact us

Key features

  • Optimized for GNSS/Wi-Fi networks
  • SMT mount
  • High efficiency

Overview

The YFMP200WWA is a compact form factor combo SMT mount antenna for Wi-Fi and GNSS dual band applications. Due to the dimensions of 3.2mm x 1.6mm × 0.6mm, it is designed for applications with very small space requirements for GPS, GLONASS, BEIDOU, Wi-Fi, WLAN, BT, Zigbee and 802.11 terminals. YFMP200WWA is a ground-dependent PIFA antenna and uses main PCB as its ground plane. It is delivered on tape and reel.

The YFMP200WWA is a combo antenna, which can be mounted on terminals in super-compact spaces. Despite this small factor, it has -12.1dB isolation in Wi-Fi and GNSS working bands. This antenna is developed on an 80mm x 40mm evaluation board. If the devices have different ground sizes, a matching circuit can be used to tune the resonant frequency correctly. We also offer gerber file, 2D and 3D documents for PCB layout.

The YFMP200WWA allows high efficiency, stable signal transmission and reception for Wi-Fi working bands in 2400–2500MHz, and GNSS working bands in 1560–1580MHz. Typical applications include: storage temperature, small-sized automotive navigation, position tracking systems, bluetooth earphone systems, hand-held devices when Bluetooth/Wi-Fi functions are needed, e.g. smart phones; IEEE802.11 b/g/n; ZigBee, and wireless PCMCIA cards or USB dongle.
