YFGA018E3AM GNSS L1 buckle mount ceramic patch + cable active embedded antenna
- Frequency band: 1559–1606MHz
- Dimensions: 18mm × 18mm × 7.5mm
- LNA gain: 16 ±3dB
- RoHS and REACH compliant
Have a question? Contact us
Key features
- Adhesive/buckle mount
- Optimized for GNSS L1/L5
- IPEX MHF 1 connector
Overview
The YFGA018E3AM is a high-performance GNSS buckle mount ceramic patch + cable active embedded antenna, designed for reliable positioning. Operating in the 1559–1606MHz range with 50Ω impedance and RHCP polarization, it supports key bands like GPS L1, GLONASS G1, GALILEO E1, BDS B1I/B1C, and QZSS L1.
With dimensions of 18mm × 18mm × 7.5mm and a 7.7g weight, it features a Φ 1.13mm black RF cable (100mm) with an IPEX MHF1 connector and buckle mounting. Its LNA gain of 16 ±3dB and noise figure ≤2.5dB enhance signal reception, complemented by 51% efficiency at 1561MHz and a peak gain of -0.46dBi.
RoHS and REACH compliant, it operates in -40°C to +85°C. Packaged in pearl cotton trays (36 pcs) and cartons (180 pcs), it suits seamless integration in GNSS-enabled devices requiring robust performance in diverse environments.
