YF0011KA Wi-Fi/BT Adhesive Mount Antenna

Summary
Specifications

- Frequency range: 2400–2500MHz, 5150–5850MHz
- Dimensions: 38.9mm × 9mm × 0.12mm
- Cable length: 44mm±3
- Peak efficiency: 78%
- RoHS and REACH compliant
Email *
Comments

Download Product Specifications
Comments
First Name *
Last Name *
Email *
Phone *
Job Title *
Company *
Country / Territory *
Province (Canada) *
State (U.S.) *
Province (China) *
Vertical market *
Vertical market subdivision *
Are you also interested in our services? Please choose one
Are you also interested in our services? Please choose one
Checkboxes *
By submitting this form, I agree that representatives from Quectel may contact me regarding its products and services. I understand I may withdraw my consent at any time. For more information please see Quectel's Privacy Policy and Terms of Service
Comments

Have a question? Contact us

Customers in APAC, EMEA or LATAM can activate and manage the connectivity of their cellular modules directly with us

Learn more

Key Features

PFC with cable adhesive mount IoT antenna
Optimized for BT/Wi-Fi networks
2.4 & 5.8GHz Wi-Fi dual-band
IPEX I connector (U.FL Generation I)

Overview

This FPC embedded antenna is a dual band device offering excellent performance for BT and 2.4GHz and 5GHz Wi-Fi/WLAN solutions. The flexibility and adhesive backing makes this antenna easy to mount in any non-metallic standard or custom enclosures. Highly efficient and ground plane independent, connection is made to the radio via the 44mm cable, terminated with a UF.L connector. Optional cable lengths and connector types available upon request. We provide comprehensive antenna design support such as simulation, testing and manufacturing for custom antenna solutions to meet your specific application needs.

Simplify deployment by sourcing antennas at the same time as your modules - see our wide range here
