YENT002W1BM LPWA/ISM terminal mount rubber monopole external antenna

  • Frequency band – 850–950MHz
  • Dimensions: 135mm × 15.6mm × 13mm
  • Efficiency: up to 70.5% (EVB)
  • RoHS and REACH compliant
  • IP rating: IP67 (after assembly)
Please enable JavaScript in your browser to complete this form.
Checkboxes

Have a question? Contact us

Key features

  • Optimized for ISM networks
  • Terminal mount
  • RP SMA male connector

Overview

The YENT002W1BM is an ISM external antenna measuring 135mm × 15.6mm × 13mm. This ultra-wide-band ISM antenna provides broad coverage from 850–950MHz. The antenna is terminated with an RP-SMA male connector. This low-profile, terminal mount omnidirectional antenna, ideal for applications where the antenna is required to be discrete, is easy to install, with maximum durability assured thanks to its PC + ABS enclosure.

The antenna is designed as monopole type to work with various GND plane sizes or in free space for ease of integration with a hinged RP SMA male connector to achieve the optimum position. The hinged structure helps to avoid other antennas or objects by rotating to different directions when mounted on terminals. This omnidirectional antenna is ideally suited for security alerts, wireless data transmission, automated manufacturing, and many other IoT devices.

Browse our wide range of antennas – download our antenna brochure

Product Brochure

Quectel_Product_Brochure_V8.6.pdf

Download
