# LPWA BG95-M3 Mini PCIe ## Summary - Multi-band LPWA module - 51.0mm × 30.0mm × 4.9mm - Mini PCIe package - Max. 588Kbps DL / 1119Kbps UL under Cat M1 - Extended temperature range of -40°C to +80°C ## Key features - Global coverage with LTE Cat M1/Cat NB2/EGPRS - Easy migration from Quectel LTE Mini PCIe modules - ARM A7 Processor - Multi-constellation GNSS receiver - USB 2.0 interface - Supports DFOTA - Fast time-to-market: reference designs, evaluation tools and timely technical support minimize design and development efforts - Robust mounting and interfaces ## Overview The BG95-M3 Mini PCIe is a multi-band LTE Cat M1/Cat NB2/EGPRS module which achieves maximum downlink rates of 588Kbps and uplink rates of 1119Kbps. It has a highly integrated and cost-effective standard PCI Express® Mini Card form factor measuring 51.0mm × 30.0mm × 4.9mm which allows integrators and developers to benefit from its mechanical intensity and low power consumption and design their applications with ease. A rich set of internet protocols, industry-standard interfaces, and abundant functionalities (e.g. USB drivers for Windows 7/8/8.1/10, Linux etc.) allow the module to serve a wide range of IoT applications such as wireless POS, smart metering, asset tracking and more. Browse our wide range of antennas – download our antenna brochure: [View brochure](https://www2.quectel.com/quectel_antenna_brochure.pdf) ## Product Brochure Quectel_Product_Brochure_V8.6.pdf: [Download](https://www.quectel.com/content/uploads/2026/05/Quectel_Product_Brochure_V8.6.pdf) ## Documentation and resources ### EVB Kit - [Quectel_Mini_PCIe_EVB_User_Guide_V1.3](https://www.quectel.com/login/?redirect=https%3A%2F%2Fwww.quectel.com%2Fproduct%2Flpwa-bg95-m3-mpcie%2F) — File Size: 1.65 MB ### Hardware Development Resources - [Quectel_BG95-M3_Mini_PCIe_2D_Dimensions_V1.0](https://www.quectel.com/login/?redirect=https%3A%2F%2Fwww.quectel.com%2Fproduct%2Flpwa-bg95-m3-mpcie%2F) — File Size: 259.02 KB - [Quectel_BG95-M3_Mini_PCIe_3D_Dimensions_V1.0](https://www.quectel.com/login/?redirect=https%3A%2F%2Fwww.quectel.com%2Fproduct%2Flpwa-bg95-m3-mpcie%2F) — File Size: 1.58 MB - [Quectel_BG95-M3_Mini_PCIe_Hardware_Design_V1.1](https://www.quectel.com/login/?redirect=https%3A%2F%2Fwww.quectel.com%2Fproduct%2Flpwa-bg95-m3-mpcie%2F) — File Size: 1.39 MB ### User Guide - [Quectel_Antenna_Design_Note_V3.4](https://www.quectel.com/login/?redirect=https%3A%2F%2Fwww.quectel.com%2Fproduct%2Flpwa-bg95-m3-mpcie%2F) — File Size: 1.14 MB ## Related products ### [YECT002W1BM 5G terminal mount rubber dipole external antenna](https://www.quectel.com/product/yect002w1bm-5g-terminal-mount-rubber-dipole-external-antenna/) ![YECT002W1BM 5G terminal mount rubber dipole external antenna](https://www.quectel.com/content/uploads/2026/09/YECT002W1BM.webp) ### [YEMN306J1AH 5G/GNSS 3-in-1 screw mount combo antenna](https://www.quectel.com/product/yemn306j1ah-5g-gnss-3-in-1-screw-mount-combo-antenna/) ![YEMN306J1AH 5G/GNSS 3-in-1 screw mount combo antenna](https://www.quectel.com/content/uploads/2026/09/YEMN306J1AH.webp) ### [YEMN203J1BH 5G 2-in-1 screw mount combo external antenna](https://www.quectel.com/product/yemn203j1bh-5g-2-in-1-screw-mount-combo-external-antenna/) ![YEMN203J1BH 5G 2-in-1 screw mount combo external antenna](https://www.quectel.com/content/uploads/2026/09/YEMN203J1BH-2.webp) ### [YECT002AA 4G external antenna](https://www.quectel.com/product/yect002aa-4g-external-antenna/) ![YECT002AA 4G external antenna](https://www.quectel.com/content/uploads/2026/09/YECT002AA.webp) ### [YEMN204J1BH 5G 2-in-1 screw mount combo antenna](https://www.quectel.com/product/yemn204j1bh-5g-2-in-1-screw-mount-combo-antenna/) ![YEMN204J1BH 5G 2-in-1 screw mount combo antenna](https://www.quectel.com/content/uploads/2026/09/YEMN204J1BH.webp) ### [YEMN303J1BM 5G/Wi-Fi/GNSS 3-in-1 screw mount combo antenna](https://www.quectel.com/product/yemn303j1bm-5g-wi-fi-gnss-3-in-1-screw-mount-combo-antenna/) ![YEMN303J1BM 5G/Wi-Fi/GNSS 3-in-1 screw mount combo antenna](https://www.quectel.com/content/uploads/2026/09/YEMN303J1BM.webp) ### [YEMN517U1AM 5G/GNSS 5-in-1 screw mount combo external antenna](https://www.quectel.com/product/yemn517u1am-5g-gnss-5-in-1-screw-mount-combo-external-antenna/) ![YEMN517U1AM 5G/GNSS 5-in-1 screw mount combo external antenna](https://www.quectel.com/content/uploads/2026/08/YEMN517U1AM.webp) ### [YE0011BA 4G terminal mount rubber monopole external antenna](https://www.quectel.com/product/ye0011ba-4g-terminal-mount-rubber-monopole-external-antenna/) ![YE0011BA 4G terminal mount rubber monopole external antenna](https://www.quectel.com/content/uploads/2026/08/YE0011BA-front-view.webp) ## Customer device profiles ### Earthquake monitoring ![Safehub](https://www.quectel.com/content/uploads/2025/01/Safehub_sensors_quectel_bg95-m3_keep_earthquake-prone_buildings_safe_hands_operating_Sensor_Plugged_1920x875-1024x467.png) ### Retail stock monitor ![CoolR Group](https://www.quectel.com/content/uploads/2024/04/cpg-customer-story-1024x683.jpg) ### Smart medicine dispenser ![MedThings](https://www.quectel.com/content/uploads/2025/04/different-tablets-on-background-in-dosage-as-from-smart-medicine-dispenser-1024x542.jpg) ## Also of interest - [LPWA BG96 Cat M1/NB1/EGPRS Mini PCIe](https://www.quectel.com/product/lpwa-bg96-cat-m1-nb1-egprs-mpcie/) - [LPWA BG95 Cat M1/Cat NB2/EGPRS series](https://www.quectel.com/product/lpwa-bg95-cat-m1-cat-nb2-egprs-series/) - [LPWA BG95 Cat M1/Cat NB2/EGPRS](https://www.quectel.com/ja/product/lpwa-bg95-cat-m1-cat-nb2-egprs/)
