GNSS LC29H series

Summary
Specifications
PCB

- High-precision, dual-band GNSS module
- 12.2mm × 16.0mm × 2.5mm
- Approx. 0.9g
- GPS, GLONASS, BDS, Galileo and QZSS
- Operating temperature of -40°C to +85°C
Email *
Comments

Download Product Specifications
Comments
First Name *
Last Name *
Email *
Phone *
Job Title *
Company *
Country / Territory *
Province (Canada) *
State (U.S.) *
Province (China) *
Vertical market *
Vertical market subdivision *
Are you also interested in our services? Please choose one
Are you also interested in our services? Please choose one
Checkboxes *
By submitting this form, I agree that representatives from Quectel may contact me regarding its products and services. I understand I may withdraw my consent at any time. For more information please see Quectel's Privacy Policy and Terms of Service
Comments
Email *
Comments
Comments
First Name *
Last Name *
Email *
Phone *
Job Title *
Company *
Country / Territory *
Province (Canada) *
State (U.S.) *
Province (China) *
Vertical market *
Vertical market subdivision *
Are you also interested in our services? Please choose one
Are you also interested in our services? Please choose one
Checkboxes *
By submitting this form, I agree that representatives from Quectel may contact me regarding its products and services. I understand I may withdraw my consent at any time. For more information please see Quectel's Privacy Policy and Terms of Service
Comments

Have a question? Contact us

Choose your variant

Click here to compare specs

Customers in APAC, EMEA or LATAM can activate and manage the connectivity of their cellular modules directly with us

Learn more

	LC29H (AA)	LC29H (BA)*	LC29H (CA)*	LC29H (DA)*	LC29H (EA)*
REGION	Global	Global	Global	Global	Global
GNSS FEATURES
SUPPORTED FEATURES	GPS/QZSS: L1 C/A, L5 GLONASS: L1 Galileo: E1, E5a BDS: B1I, B2a	GPS/QZSS: L1 C/A, L5 GLONASS: L1 Galileo: E1, E5a BDS: B1I, B2a	GPS/QZSS: L1 C/A, L5 GLONASS: L1 Galileo: E1, E5a BDS: B1I, B2a	GPS/QZSS: L1 C/A, L5 GLONASS: L1 Galileo: E1, E5a BDS: B1I, B2a	GPS/QZSS: L1 C/A, L5 GLONASS: L1 Galileo: E1, E5a BDS: B1I, B2a
DEFAULT GNSS CONSTELLATIONS	GPS + GLONASS + Galileo + BDS + QZSS	GPS + GLONASS + Galileo + BDS + QZSS	GPS + GLONASS + Galileo + BDS + QZSS	GPS + GLONASS + Galileo + BDS + QZSS	GPS + GLONASS + Galileo + BDS + QZSS
NUMBER OF CONCURRENT GNSS	5	5	5	5	5
SBAS	WAAS, EGNOS, MSAS and GAGAN	WAAS, EGNOS, MSAS and GAGAN	WAAS, EGNOS, MSAS and GAGAN	WAAS, EGNOS, MSAS and GAGAN	WAAS, EGNOS, MSAS and GAGAN
RTK/DR	-	RTK + DR	DR	RTK	RTK
HORIZONTAL POSITION ACCURACY	Autonomous①: 1 m	Autonomous①: 1 m RTK②: TBD	Autonomous①: 1 m	Autonomous①: 1 m RTK②: TBD	Autonomous①: 1 m RTK②: TBD
VELOCITY ACCURACY	Without Aid: TBD	Without Aid: TBD	Without Aid: TBD	Without Aid: TBD	Without Aid: TBD
ACCELERATION ACCURACY	Without Aid: TBD	Without Aid: TBD	Without Aid: TBD	Without Aid: TBD	Without Aid: TBD
ACCURACY OF 1PPS SIGNAL③	100 ns	100 ns	100 ns	100 ns	100 ns
CONVERGENCE TIME	-	RTK②: 10 s	-	RTK②: 10 s	RTK②: 10 s
TTFF (with AGNSS)④	Full Cold Start: 16 s Warm Start: 2 s Hot Start: 1 s	Cold Start: TBD Warm Start: TBD Hot Start: TBD	Cold Start: TBD Warm Start: TBD Hot Start: TBD	Cold Start: TBD Warm Start: TBD Hot Start: TBD	Cold Start: TBD Warm Start: TBD Hot Start: TBD
TTFF (without AGNSS)③	Full Cold Start: 31 s Warm Start: 24 s Hot Start: 1 s	Cold Start: TBD Warm Start: TBD Hot Start: TBD	Cold Start: TBD Warm Start: TBD Hot Start: TBD	Cold Start: TBD Warm Start: TBD Hot Start: TBD	Cold Start: TBD Warm Start: TBD Hot Start: TBD
SENSITIVITY (@ Default Constellations)	Acquisition: -147dBm Tracking: -165dBm Reacquisition: -159dBm	Acquisition: -147dBm Tracking: -165dBm Reacquisition: -159dBm	Acquisition: -147dBm Tracking: -165dBm Reacquisition: -159dBm	Acquisition: TBD Tracking: TBD Reacquisition: TBD	Acquisition: TBD Tracking: TBD Reacquisition: TBD
DYNAMIC PERFORMANCE③	Maximum Altitude: 10000m Maximum Velocity⑤: 500m/s Maximum Acceleration⑤: 4g	Maximum Altitude: 10000m Maximum Velocity⑤: 500m/s Maximum Acceleration⑤: 4g	Maximum Altitude: 10000m Maximum Velocity⑤: 500m/s Maximum Acceleration⑤: 4g	Maximum Altitude: 10000m Maximum Velocity⑤: 500m/s Maximum Acceleration⑤: 4g	Maximum Altitude: 10000m Maximum Velocity⑤: 500m/s Maximum Acceleration⑤: 4g
UPDATE RATE	1 Hz (Default); Max. 10Hz	GNSS Raw Data: 1Hz IMU Raw Data: 1Hz (Default); Max. 10Hz	IMU Raw Data: 1Hz (Default); Max. 10Hz	GNSS Raw Data: 1Hz	GNSS Raw Data: 10Hz
CERTIFICATIONS
REGULATORY	Europe: CE*	Europe: CE*	Europe: CE*	Europe: CE*
OTHERS	RoHS*	RoHS*	RoHS*	RoHS*	RoHS*
ELECTRICAL CHARACTERISTICS
SUPPLY VOLTAGE RANGE (V)	3.1–3.6, Typ. 3.3	3.1–3.6, Typ. 3.3	3.1–3.6, Typ. 3.3	3.1–3.6, Typ. 3.3	3.1–3.6, Typ. 3.3
I/O VOLTAGE (V)	Typ. 2.8	Typ. 2.8	Typ. 2.8	Typ. 2.8	Typ. 2.8
CURRENT CONSUMPTION (@ Default GNSS Constellations, 3.3 V)③	Normal Operation: 30 mA @ Acquisition 30 mA @ Tracking Power Saving Modes: 6.6 mA @ Standby Mode 25 μA @ Backup Mode	Normal Operation: 30 mA @ Acquisition 30 mA @ Tracking Power Saving Modes: 6.6 mA @ Standby Mode 25 μA @ Backup Mode	Normal Operation: 30 mA @ Acquisition 30 mA @ Tracking Power Saving Modes: 6.6 mA @ Standby Mode 25 μA @ Backup Mode	Normal Operation: TBD @ Acquisition TBD @ Tracking Power Saving Modes: TBD @ Standby Mode TBD @ Backup Mode	Normal Operation: TBD @ Acquisition TBD @ Tracking Power Saving Modes: TBD @ Standby Mode TBD @ Backup Mode
	LC29H (AA)	LC29H (BA)*	LC29H (CA)*	LC29H (DA)*	LC29H (EA)*

Key Features

Multi-GNSS engine for GPS, GLONASS, BDS, Galileo and QZSS
Reception of L1 and L5 GNSS bands signals concurrently
Integrated DR function (optional)
RTK (optional) providing sub-meter accuracy with fast convergence time and outstanding performance
Integrated LNA for high sensitivity
Integrated SAW filter for noise cancellation
UART, I2C and SPI* interfaces
Integrated AGNSS function
Integrated AIC and jamming function

*: under development

Overview

LC29H is a series of dual-band, multi-constellation GNSS modules that support the concurrent reception of all four global GNSS constellations: GPS, BDS, Galileo and GLONASS.

Compared to GNSS modules that track only L1 signals, the LC29H series can receive and track a higher number of visible satellites in multi bands, thereby significantly mitigating the multipath effect in deep urban canyons and improving positioning accuracy. By having an internal LNA and SAW filter, the module achieves better sensitivity and anti-interference capability. Featuring dual frequency support, the module delivers CEP accuracy values of 1 m in autonomous mode and centimeter levels in the RTK capable variants. The optional DR function ensures the module’s superior positioning performance even in weak signal areas or when GNSS signals are not available.

Based on the receiver chip using 12 nm technology, the LC29H series provides advanced power management enabling low-power GNSS sensing and position fix, which makes the module an ideal solution for power-sensitive and battery-powered systems. Featuring high-precision positioning and low power consumption makes the LC29H series perfectly suited for applications such as real time tracking and sharing economy related services.
