YRPAD109G3AM 5G adhesive mount PCB + cable dipole embedded antenna

  • Frequency band: 600–6000 MHz
  • Dimensions: 78.6 mm × 14.2 mm × 0.95 mm
  • Cable length: 202 mm
  • Efficiency: up to 79.2 % (FS)
  • RoHS and REACH compliant
Please enable JavaScript in your browser to complete this form.
Checkboxes

Have a question? Contact us

Key features

  • Optimized for 5G networks
  • Adhesive mount
  • IPEX MHF 1 connector
  • High efficiency
  • Excellent performance

Overview

The YRPAD109G3AM is a 5G PCB antenna measuring 78.6 mm × 14.2 mm × 0.95 mm. This 5G antenna provides coverage from 600–6000 MHz. The antenna has a 202 mm long cable, terminated with an IPEX MHF 1 connector, and is available with customized cable lengths and connectors. This adhesive mount omni-directional antenna, ideal for applications where the antenna is required to be mounted inside, is easy to install thanks to its rigid PCB material. It has been tested with ABS board.

The YRPAD109G3AM is designed as a PCB antenna, which is built on a printed circuit board and delivers high efficiency across various mounting scenarios. It is the perfect antenna product for customers that desire the highest performance. This high-efficiency, high-gain omni-directional antenna is ideally suited to smart metering, remote monitoring, vehicle tracking and telematics, and many other IoT devices
