GNSS IoT Modules

The Global Navigation Satellite System (GNSS) is a widely deployed and accepted way to determine location precisely without needing to rely on coverage or signal strength of cellular networks. It therefore underpins navigation, tracking and tracing of a wide variety of goods and assets and billions of GNSS IoT devices are now deployed worldwide.

However, GNSS applications are not one-size-fits-all and there are some considerable challenges for organizations to find and adapt the right solutions to deliver their applications. Where automotive solutions lack a clear view of satellites for instance, caused by dense buildings or bad weather, it can be very challenging for any GNSS module to provide an accurate position - which is compounded by multipath effects prevalent in deep urban canyons. Here, innovations such as dead reckoning can help, which can use information from sensors such as the accelerometer to augment the performance of GNSS positioning. Innovators need to know which approach works best for them - and that is where we can help.

Quectel’s wide range of ultra-compact, low-power GNSS modules cover the full range of requirements in standard precision, high precision, dead reckoning and timing, for application scenarios as diverse as ADAS and self-driving, unmanned flight, and smart agriculture. And, with unsurpassed aftermarket support services, the journey with us does not end with a purchase - that's just the beginning.

Use cases include

  • Asset tracking
  • Automotive
  • Drones
  • Fleet management
  • Industrial PDAs
  • Micromobility
  • Personal/pet tracking
  • Portable devices
  • Remote monitoring
  • Sharing economy
  • Wearable devices



  • Module Single/dual band Constellations Key features Sensitivity See more
    Single
    GPS
    GLONASS
    BeiDou
    QZSS
    Anti-jamming
    Multiple low-power modes
    Supports UART and I2C
    Acquisition: -147dBm
    Tracking: -156dBm
    Reacquisition: -158dBm
    Single
    GPS
    GLONASS
    BeiDou
    QZSS
    Anti-jamming
    Integrated LNA
    Supports UART and I2C
    Acquisition: -147dBm
    Tracking: -166dBm
    Reacquisition: -159dBm
    Single
    GPS
    GLONASS
    BeiDou
    QZSS
    Integrated LNA
    Multiple low-power modes
    Supports UART and I2C
    Available for sale in Europe and APAC
    Acquisition: -148dBm
    Tracking: -165dBm
    Reacquisition: -162dBm
    Single
    GPS
    GLONASS
    BeiDou
    Galileo
    QZSS
    Balloon mode
    Supports SBAS
    Ultra-low power consumption
    Acquisition: -148dBm
    Tracking: -165dBm
    Reacquisition: -160dBm
    Single
    GPS
    GLONASS
    Galileo
    QZSS
    2.8V and 1.8V I/O voltage available
    Supports multiple low-power modes
    PPS VS. NMEA
    Acquisition: -149dBm
    Tracking: -167dBm
    Reacquisition: -161dBm
    Single
    GPS
    QZSS
    FLP: 5mA in static receiving
    SBAS (WAAS/EGNOS/MSAS/GAGAN)
    PPS VS. NMEA
    Acquisition: -148dBm
    Tracking: -165dBm
    Reacquisition: -160dBm
    Single
    GPS
    QZSS
    Ultra-low power consumption
    Balloon mode
    PPS VS. NMEA
    Acquisition: -148dBm
    Tracking: -165dBm
    Reacquisition: -160dBm
    Single
    GPS
    GLONASS
    Galileo
    QZSS
    Built-in LNA
    Balloon mode
    PPS VS. NMEA
    Acquisition: -149dBm
    Tracking: -167dBm
    Reacquisition: -161dBm
    Single
    GPS
    GLONASS
    Galileo
    QZSS
    Built-in LNA
    Ultra-low power consumption
    Supports short circuit protection
    Acquisition: -148dBm
    Tracking: -167dBm
    Reacquisition: -160dBm
  • Module Single/dual band Constellations Key features Sensitivity See more
    Dual
    GPS
    GLONASS
    BeiDou
    Galileo
    QZSS
    Supports AGNSS
    Built-in LNA and SAW filter
    UART and I2C
    Acquisition: -148dBm LC79H (AL)
    Acquisition: -147dBm LC79H (BA)
    Tracking: -166dBm LC79H (AL)
    Tracking: -164dBm LC79H (BA)
    Reacquisition: -159dBm LC79H (AL)
    Reacquisition: -158dBm LC79H (BA)
    Dual
    GPS
    GLONASS
    BeiDou
    Galileo
    QZSS
    IRNSS
    Supports AGNSS
    Built-in LNA
    Two/four-wheel DR functions
    Acquisition: -147dBm
    Tracking: -163dBm
    Reacquisition: -158dBm
    Dual
    GPS
    GLONASS
    Galileo
    IRNSS
    BeiDou
    QZSS
    Integrated 6-axis sensor
    Supports AGNSS
    Built-in LNA
    Dead reckoning
    Supports RTK
    Acquisition: -148dBm
    Tracking: -163dBm (LC29D-A/-C)
    Tracking: -162dBm (LC29D-B)
    Reacquisition: -158dBm (LC29D-A)
    Reacquisition: -157dBm (LC29D-B/-C)
    Single
    GPS
    GLONASS
    Galileo
    BeiDou
    QZSS
    IMU RAW DATA function
    Built-in LNA
    Integrated 6-axis sensor (IMU)
    DDGPS (RTCM)
    SBAS (WAAS/EGNOS/MSAS/GAGAN)
    Acquisition: -147dBm
    Tracking: -162dBm
    Reacquisition: -154dBm
  • Module Single/dual band Constellations Key features Sensitivity See more
    Dual
    GPS
    GLONASS
    Galileo
    BeiDou
    QZSS
    NAVIC
    Automotive grade
    Built-in LNA
    cm-level accuracy
    Multi-band RTK
    TESEO V chip
    Cold Start: -147dBm
    Tracking: -160dBm
    Reacquisition: -153dBm
    Dual
    GPS
    GLONASS
    Galileo
    BeiDou
    QZSS
    Supports RTK
    Integrated SAW filters
    B13 band suppression design
    Supports EPO™, EASY™, LOCUS™
    Dead reckoning
    Acquisition: -147dBm
    Tracking: -165dBm
    Reacquisition: -162dBm
    Single
    GPS
    GLONASS
    Galileo
    BeiDou
    QZSS
    Ultracompact size
    Integrated AGNSS function
    Single-satellite timing feature
    Anti-jamming
    Acquisition: -146dBm
    Tracking: -161dBm
    Reacquisition: -155dBm
  • Module Single/dual band Constellations Key features Sensitivity See more
    Single
    GPS
    GLONASS
    BeiDou
    Galileo
    QZSS
    Automotive grade
    Built-in LNA
    Embedded 6-axis MEMS sensor
    Supports DGPS and SBAS
    Wheel tick input
    Acquisition: -145dBm
    Tracking: -162dBm
    Reacquisition: -152dBm
    Dual
    GPS
    GLONASS
    Galileo
    IRNSS
    BeiDou
    QZSS
    Integrated 6-axis sensor
    Supports AGNSS
    Built-in LNA
    Dead reckoning
    Supports RTK
    Acquisition: -148dBm
    Tracking: -163dBm (LC29D-A/-C)
    Tracking: -162dBm (LC29D-B)
    Reacquisition: -158dBm (LC29D-A)
    Reacquisition: -157dBm (LC29D-B/-C)
    Dual
    GPS
    GLONASS
    Galileo
    BeiDou
    QZSS
    Supports RTK
    Integrated SAW filters
    B13 band suppression design
    Supports EPO™, EASY™, LOCUS™
    Dead reckoning
    Acquisition: -147dBm
    Tracking: -165dBm
    Reacquisition: -162dBm
    Dual
    GPS
    GLONASS
    BeiDou
    Galileo
    QZSS
    IRNSS
    Supports AGNSS
    Built-in LNA
    Two/four-wheel DR functions
    Acquisition: -147dBm
    Tracking: -163dBm
    Reacquisition: -158dBm
    Dual
    GPS
    GLONASS
    Galileo
    BeiDou
    QZSS
    NAVIC
    Automotive grade
    Built-in LNA
    cm-level accuracy
    Multi-band RTK
    TESEO V chip
    Cold Start: -147dBm
    Tracking: -160dBm
    Reacquisition: -153dBm
  • Module Single/dual band Constellations Key features Sensitivity See more
    Single
    GPS
    GLONASS
    BeiDou
    Galileo (RLM supported)
    QZSS
    Built-in LNA
    Supports AGNSS
    Supports DGPS
    Supports multi-GNSS raw data
    TESEO III chip
    Acquisition: -147dBm
    Tracking: -162dBm
    Reacquisition: -154dBm
    Single
    GPS
    GLONASS
    BeiDou
    Galileo
    QZSS
    Ultracompact size
    Integrated AGNSS function
    Single-satellite timing feature
    Anti-jamming
    Acquisition: -146dBm
    Tracking: -161dBm
    Reacquisition: -155dBm
  • Module Single/dual band Constellations Key features Sensitivity See more
    Single
    GPS
    GLONASS
    BeiDou
    Galileo (RLM supported)
    QZSS
    Embedded chip antenna
    Built-in LNA
    Dual SAW filters
    Balloon mode
    Acquisition: -148dBm
    Tracking: -165dBm
    Reacquisition: -160dBm
    Single
    GPS
    GLONASS
    BeiDou
    Galileo
    QZSS
    Embedded patch antenna
    Automatic antenna switching
    Built-in LNA
    Ultra-low power consumption
    Supports short circuit protection
    Acquisition: -149dBm
    Tracking: -161dBm
    Reacquisition: -167dBm
    Single
    GPS
    GLONASS
    BeiDou
    Galileo
    QZSS
    Integrated patch antenna
    Integrated LNA
    AG3331/MT3333 chip
    Automatic antenna switching
    Antenna detection
    Acquisition: -148dBm
    Tracking: -161dBm
    Reacquisition: -166dBm
  •
