YENM001L1AH LPWA/ISM magnetic mount whip monopole external antenna
- Frequency band: 433–435MHz, 450–470MHz
- Dimensions: Φ30mm × 82.2mm
- Efficiency: up to 40.1%
- RoHS and REACH compliant
- IP rating: IP67
Have a question? Contact us
Key features
- Optimized for ISM networks
- SMA male connector
- Magnetic mount
Overview
YENM001L1AH is an ISM external antenna measuring Φ30mm × 82.2mm. This ISM antenna provides coverage from 433–435MHz, 450–470MHz. The antenna is available with connection via cable lengths from 300–5000mm, terminated with a SMA male (center pin) connector. Ideal for applications where the antenna is required to be discreet, this low profile, magnetic mount omni-directional antenna is easy to install with maximum durability assured thanks to its IP67 rated and ASA enclosure. It is compatible with Quectel’s ISM series modules.
It allows constant and reliable transmission and reception due to its omni-directional gain across all frequency bands. YENM001L1AH is designed as a monopole antenna, which offers high efficiency in all working bands. It is a perfect antenna product for customers that desire highest performance. This high efficiency, high-gain omni-directional antenna is ideally suited for security alerts, wireless data transmission, automated manufacturing, and many other IoT devices. It is suitable for outdoor and indoor applications due to its robust UV resistant ASA enclosure, which meets UL 746C f1. Typical applications include security alerts, wireless data-transmission, automated manufacturing, and industrial IoT.
