YECT001W1WM 4G terminal mount rubber monopole external antenna
- Frequency band: 698–960MHz, 1710–2690MHz
- Dimensions: 52.6mm x 18.6mm x 9mm
- Efficiency: up to 68.9%
- RoHS and REACH compliant
- IP rating: IP54
Have a question? Contact us
Key features
- Optimized for 4G networks
- Terminal mount
- SMA male connector
Overview
The YECT001W1WM is a 4G rubber antenna measuring 52.6mm x 18.6mm x 9mm. This ultra-wide-band 4G antenna provides broad coverage from 698–960MHz, 1710–2690MHz whilst offering backward-compatibility to support 3G and 2G networks as well as LTE Cat-M and narrowband IoT (NB-IoT). The antenna is terminated with a 90° SMA male connector. This low profile, terminal mount omni-directional antenna, ideal for applications where the antenna is required to be discrete, is easy to install, with maximum durability assured thanks to its TPE enclosure. It is compatible with Quectel’s 4G series modules.
It allows constant and reliable transmission and reception due to its omni-directional gain across all frequency bands. The YECT001W1WM is designed as a monopole antenna, which needs to be mounted on a ground plane to offer high efficiency in all working bands. It is the perfect antenna product for customers that desire the highest performance. This high-efficiency, high-gain omni-directional antenna is ideally suited for Zigbee, Bluetooth, IoT sensors, public safety and security, point of sales terminals, smart home automation, and robotics / autonomous.
