YFGA010E3AM GNSS L1 buckle mount ceramic patch + cable active embedded antenna
- Frequency band: 1559–1606MHz
- Dimensions: 10.2mm x 10.2mm x 7.5mm
- RoHS and REACH compliant
Have a question? Contact us
Key features
- Optimized for GNSS L1
- Adhesive/buckle mount
- IPEX MHF 1 connector
- LNA gain: 16 ±3dB
Overview
The YFGA010E3AM is a compact, high-performance active GNSS antenna designed for precise positioning applications. It operates in the GPS L1 frequency band (1565–1586MHz) and supports RHCP (Right-Hand Circular Polarization) for improved signal reliability.
Key features:
- Dimensions: 10.2mm x 10.2mm x 7.5mm
- LNA gain: 16 ±3dB
- Noise figure: ≤ 2.5dB
- Impedance: 50Ω
- VSWR: 1.39 (at 1575MHz)
- Return loss: -15.7dB
- Radiation efficiency: 16%
- Peak gain: -4.57dBi
Supported systems:
- GPS L1, Galileo E1, BDS B1C, QZSS L1
- Electrical and environmental:
- Operating voltage: 1.8–3.3V
- Current consumption: 4.3 ±1.5mA
- Operating temperature: -40°C to +85°C
- RoHS and REACH compliant: Yes
Mechanical and connection:
- Connector: IPEX MHF1
- Cable: Φ 1.13mm, 100mm length, black
- Mounting type: Buckle
- Weight: Typ. 3.3g
