YFGA005AA GNSS L1 adhesive mount FPC + cable passive embedded antenna

  • Frequency band: 1559–1606MHz
  • Dimensions: 61.5mm x 11.24mm
  • Cable length: 100mm
  • Efficiency: up to 66.9%
Please enable JavaScript in your browser to complete this form.
Checkboxes
Please enable JavaScript in your browser to complete this form.
Checkboxes

Have a question? Contact us

Features

  • Optimized for GNSS L1
  • Flexible ‘peel and stick’ antenna
  • RF I connector

Overview

The YFGA005AA is a GNSS FPC antenna measuring 61.15mm x 11.24mm. This GNSS antenna provides coverage from 1559–1606MHz. The antenna has a 100.5mm-long cable, terminated with IPEX MHF 1 connector, and is available with customized cable lengths and connectors. Ideal for applications where the antenna is required to be mounted inside, this adhesive mount omni-directional antenna is easy to install thanks to its flexible material. It is compatible with Quectel’s GNSS Series modules. It has been tested with ABS board.

It allows constant and reliable transmission and reception due to its omni-directional gain across all frequency bands. The YFGA005AA is designed as a linear polarized antenna, which has low VSWR for low power consumption applications. It is the perfect antenna product for customers that desire the highest performance. This high-efficiency, high-gain omni-directional antenna is ideally suited for telematics, fleet management, and positioning.

Simplify deployment by sourcing antennas at the same time as your modules – see our wide range here
