YFGA003AA GNSS L1 cable passive FPC + cable passive embedded antenna

- Frequency band: 1559–1609MHz
- Dimensions: 39.45mm × 13.25mm
- Cable length: 100mm
- Efficiency: up to 55.7%
Have a question? Contact us
Features
- Optimized for GNSS L1
- Flexible ‘peel and stick’ antenna
- RF I connector
Overview
The YFGA003AA is a GNSS FPC antenna measuring 39.45mm × 13.25mm. This GNSS antenna provides coverage from 1559–1606MHz. The antenna has a 100mm-long cable, terminated with an RF 1 connector, and is available with customized cable lengths and connectors. Ideal for applications where the antenna is required to be mounted inside, this adhesive mount omni-directional antenna, is easy to install thanks to its flexible material. It is compatible with Quectel’s GNSS Series modules. It has been tested with ABS board.
It allows constant and reliable transmission and reception due to its omni-directional gain across all frequency bands. The YFGA003AA is designed as a linear polarized antenna, which has low VSWR for low power consumption applications. It is the perfect antenna product for customers that desire the highest performance. This high-efficiency, high-gain omni-directional antenna is ideally suited for telematics, fleet management, and positioning.
