YECT012W1AM 4G terminal mount rubber dipole external antenna
- Frequency band: 698–960MHz, 1710–2690MHz
- Dimensions: 135mm x 15.6mm x 13mm
- Efficiency: up to 69.8% (EVB)
- RoHS compliant
Have a question? Contact us
Key features
- Optimized for 4G networks
- Terminal mount
- SMA male connector
- Compatible with FAKRA, TNC and N-type connectors
Overview
The YECT012W1AM is a 4G external antenna measuring 135mm x 15.6mm x 13mm. This ultra-wide-band 4G antenna provides broad coverage from 698–960MHz and 1710–2690MHz whilst offering backward-compatibility to support 3G and 2G networks as well as LTE Cat-M and narrowband IoT (NB-IoT). The antenna is terminated with an SMA male connector. Ideal for applications where the antenna is required to be discreet, this low profile, terminal mount omni-directional antenna is easy to install, with maximum durability assured thanks to its IP67 rated, PC + ABS enclosure.
The antenna is designed as dipole type to work with various GND plane sizes or in free space for ease of integration with a hinged SMA male connector to achieve the optimum position. The hinged structure helps to avoid other antennas or objects by rotating to different directions when mounted on terminals. This omni-directional antenna is ideally suited for gateways and routers, smart metering, vending machines, industrial IoT, smart home, connected enterprise, offering great performance with its high gain and efficiency.
