# Wi-Fi & Bluetooth FLM163D ## Summary - 2.4GHz single band Wi-Fi 6 and BLE 5.2 module - DIP form factor - 17.9mm ×15.0mm × 2.8mm - Operating temperature: -40°C to +85°C Have a question? [Contact us](https://www.quectel.com/product/wi-fi-bluetooth-flm163d#contact) ## Key features - Wi-Fi 6 module, single band (2.4 GHz) - BLE 5.2 and Wi-Fi pairing via Bluetooth - Built-in PCB antenna - Large memory – 512KB SRAM and 4MB flash - 8 GPIO interfaces – can be multiplexed as UART, I2C, PWM, ADC, etc. ## Overview FLM163D is a cutting-edge MCU Wi-Fi 6 and Bluetooth module launched by Quectel. It has a built-in 32-bit RISC-V processor with a frequency of up to 320MHz and supports IEEE 802.11b/g/n/ax protocol and BLE 5.2. The module features built-in 512KB SRAM and 4MB flash, complies with WPA-PSK, WPA2-PSK, and WPA3-SAE security standards, integrates the Mbed TLS encryption library, and supports the secure boot security startup mechanism. FLM163D is in a DIP form factor with an ultra-compact size of 17.9mm × 15.0mm × 2.8mm, which optimizes the size and cost for end-products and is compatible with diverse designs. FLM163D provides 8 GPIO interfaces, which can be multiplexed as UART, PWM, I2C, ADC and other interfaces. It has an operating temperature of – 40℃ ~ +85 ℃ and is suitable for smart devices such as sockets and converters. FLM163D integrates the [ACK SDK for Matter](https://www.quectel.com/ack-sdk-matter-amazon-alexa/) solution, which enables terminal products to quickly and efficiently access the Amazon Alexa platform and can be interconnected with other smart devices that support the Matter protocol. Browse our wide range of antennas – download our antenna brochure. [View brochure](https://www2.quectel.com/quectel_antenna_brochure.pdf) ## Product Brochure Quectel_Product_Brochure_V8.6.pdf [Download](https://www.quectel.com/content/uploads/2026/05/Quectel_Product_Brochure_V8.6.pdf) ## Documentation and resources ### Hardware Development Resources - [Quectel_FLM163D_Hardware_Design_V1.0](https://www.quectel.com/login/?redirect=https%3A%2F%2Fwww.quectel.com%2Fproduct%2Fwi-fi-bluetooth-flm163d%2F) — File Size: 1.17 MB - [Quectel_FLM163D_2D_Dimensions_V1.0](https://www.quectel.com/login/?redirect=https%3A%2F%2Fwww.quectel.com%2Fproduct%2Fwi-fi-bluetooth-flm163d%2F) — File Size: 125.05 KB - [Quectel_FLM163D_3D_Dimensions_V1.0](https://www.quectel.com/login/?redirect=https%3A%2F%2Fwww.quectel.com%2Fproduct%2Fwi-fi-bluetooth-flm163d%2F) — File Size: 590.75 KB - [Quectel_FLM163D_Footprint&Part_V1.0](https://www.quectel.com/login/?redirect=https%3A%2F%2Fwww.quectel.com%2Fproduct%2Fwi-fi-bluetooth-flm163d%2F) — File Size: 720.29 KB ## Related products ### [YEBA000G1AM Wi-Fi adhesive mount rubber monopole external antenna](https://www.quectel.com/product/yeba000g1am-wi-fi-adhesive-mount-rubber-monopole-external-antenna/) ![YEBA000G1AM Wi-Fi adhesive mount rubber monopole external antenna](https://www.quectel.com/content/uploads/2026/08/YEBA000G1AM.webp) ### [YEBT038WFA Wi-Fi terminal mount rubber external antenna](https://www.quectel.com/product/yebt038wfa-wi-fi-terminal-mount-rubber-external-antenna/) ![YEBT038WFA Wi-Fi terminal mount rubber external antenna](https://www.quectel.com/content/uploads/2026/08/YEBT038WFA.webp) ### [YEMJ4F0JBAM 5G 4-in-1 screw mount combo external antenna](https://www.quectel.com/product/yemj4f0jbam-5g-4-in-1-screw-mount-combo-external-antenna/) ![YEMJ4F0JBAM 5G 4-in-1 screw mount combo external antenna](https://www.quectel.com/content/uploads/2026/06/YEMJ4F0JBAM_Front-resized.webp) ### [YEMN208L1AM 5G/Wi-Fi 2-in-1 multiple mount combo external antenna](https://www.quectel.com/product/yemn208l1am-5g-wi-fi-2in1-combo-antenna/) ![YEMN208L1AM 5G/Wi-Fi 2-in-1 multiple mount combo external antenna](https://www.quectel.com/content/uploads/2026/05/YEMN208L1AM.webp) ### [YECT061W1BM Wi-Fi terminal mount rubber monopole antenna](https://www.quectel.com/product/yect061w1bm-wi-fi-rubber-monopole-antenna/) ![YECT061W1BM Wi-Fi terminal mount rubber monopole antenna](https://www.quectel.com/content/uploads/2026/05/YECT061W1BM.webp) ### [YEMN410L1AM 4G/Wi-Fi/GNSS 4-in-1 screw mount combo external antenna](https://www.quectel.com/product/yemn410l1am-4g-wi-fi-gnss-4in1-combo-antenna/) ![YEMN410L1AM 4G/Wi-Fi/GNSS 4-in-1 screw mount combo external antenna](https://www.quectel.com/content/uploads/2026/05/YEMN410L1AM.webp) ### [YEBT013W7AM-CN Wi-Fi terminal mount fiberglass dipole external antenna](https://www.quectel.com/product/yebt013w7am-cn-wi-fi-terminal-mount-fiberglass-dipole-external-antenna/) ![YEBT013W7AM-CN Wi-Fi terminal mount fiberglass dipole external antenna](https://www.quectel.com/content/uploads/2026/05/YEBT013W7AM-CN.webp) ### [YFBP001WWB Wi-Fi SMT mount PCB chip IFA embedded antenna](https://www.quectel.com/product/yfbp001wwb-wifi-smt-mount-pcb-chip-ifa-embedded-antenna/) ![YFBP001WWB Wi-Fi SMT mount PCB chip IFA embedded antenna](https://www.quectel.com/content/uploads/2024/09/YFBP001WWB_505x280.png) ## Also of interest - [Small cell antennas white paper](https://www.quectel.com/) - [Product selector](https://www.quectel.com/product-selector/) - [Automotive modules](https://www.quectel.com/automotive-iot-modules/)
